Product Specifications
Product Specifications
Product Code: 2HF2
Frame Size: 100L to 315LX
Power: 3.7 to 250.0 kW
Polarity: 2, 4
Mounting: B3, B5, B14 or Special
Voltage: 415V ±10% or as required
Frequency: 50Hz ±5% or as required
Protection: IP55 or superior on request
Ambient: 40ºC
Altitude: Up to 1000m above m.s.l.
Enclosure: Totally Enclosed Fan Cooled (TEFC)
Ins Class: Class F insulation with temp rise limited to class F
Performance: As per IS: 12615
